Restaurant Outline

Returns the outline data set for restaurant (core plus a subset suitable for a listing)

URL

https://api.restaurantcollective.io/api/restaurant_outline
Method

POST
URL Params

NONE
URL Body

{
    user_code : '(your_user_code)',
    api_key : '(your_api_key)',
    restaurant_number : '(specific restaurant number)'
}

Compulsory Parameters
- your_user_code (string) - as specified by RDL
- your_api_key (string) - as specified by RDL
- your_restaurant_number (string) - as specified by RDL

Successful Responses

200 OK

Content:

{
    restaurant_outline : restaurant_outline,
    status: 'OK',
    accessed: now,
    info : {
        "version": "V1.1beta",
        "release": "28/04/22",
        "tag": "RDL-API"
    }
}

Where restaurant_outline is a JSON structure that contains all currently available core data plus a subset of additional data for a restaurant (values in bold should always be returned):

number string
group_name string
name string
address_1 string
address_2 string
address_3 string
post_code string
region string
country_code string
lat number
lng number
telephone string
email string
website string
spw_url string
spw_type string [ member / curated / stock ]
facebook string
twitter string
instagram string
opening_hours
cuisine_1 string
cuisine_2 string
image_cdn: string
default_image_path: string
opening_hours: object
opening_notes: string
attributes: object
description string
last_updated string

Error Responses

400 BAD REQUEST

Content:

{
    error : 'Invalid Restaurant Number',
    status : 'FAIL',
    accessed : (datetime),
    api_version : {
        version : 'V1.0beta',
        release : '28/04/22',
        tag : 'RDL_API'
    }
}

403 UNAUTHORISED

Content:

{
    error : 'Failed to verify user',
    status : 'FORBIDDEN',
    accessed : (datetime),
    api_version : {
        "version": "V1.1beta",
        "release": "28/04/22",
        "tag": "RDL-API"
    }
}

Error texts can also be 'No restaurants authorised for this api user', 'Restaurant (number) is not authorised for this api user', 'Unable to determine if restaurant is authorised', 'Failed to read api users database'. In all cases if these cannot be resolved, please contact our technical support team.

404 DATABASE ERROR

Content:

{
    error : '(message)',
    status : 'FAIL',
    accessed : (datetime),
    api_version : {
        "version": "V1.1beta",
        "release": "28/04/22",
        "tag": "RDL-API"
    }
}

Implementation

HTML / JavaScript

As would appear in a script

    let api_params = {
      user_code : '(your_user_code)',
      api_key : '(your_api_key)',
      restaurant_number : 'EN044999999'
    };

    let xhr_bkg_request = new XMLHttpRequest();
    xhr_bkg_request.open('POST',
      'https://api.restaurantcollective.io/api/outline', true);
      xhr_bkg_request.setRequestHeader('Content-Type', 'application/json;charset=UTF-8');
      xhr_bkg_request.send(JSON.stringify(api_params));

Angular / TypeScript

As would appear in an Angular service

 getRestaurantOutline(user_code, api_key, number) {
    return this.http.post('https://api.restaurantcollective.io/api/restaurant_outline',
      {
        user_code : '(your_user_code)',
        api_key : '(your_api_key)',
        restaurant_number
    }
 }

Examples of Use

These settings are required in the POST request body. If testing from Postman or a similar API test app, set the body format to x-www-form-urlencoded.

To return detail content for one restaurant

{
  user_code : 'TT9999',
  api_key : 'TESTAPIKEYASISSUEDBYRDLBYCHANNEL'
  number : 'EN044999999'
}

returns restaurant_outline:

{
  number: "EN03392596",
  group_name: "RDL",
  name: "RC Demo Restaurant",

  address_1: "Kineton House, 31 Horsefair",
  address_2: "Banbury",
  address_3: "Oxfordshire",
  post_code: "OX16 0AE",
  country_code: "GB",
  lat: 52.0607,
  lng: 1.33956,

  telephone: "+44 7734038999",
  email: "info@restaurantcollective.org.uk",
  website: "https://restaurantcollective.org.uk",
  spw_url: "https://spw.restaurantcollective.org.uk/92596-rc-demo-restaurant/",
  spw_type: "member",

  facebook: "https://faceboook.com/restaurantcollective",
  twitter: "https://twitter.com/RCollectiveUK",
  instagram: "https://instagram.com/restaurantcollectiveuk",

  cuisine_1: "British",
  cuisine_2: "Cafe",

  opening_hours: {
  	0: "Sun: Closed all day"
	1: "Mon: 08:00 - 18:00"
	2: "Tue: 08:00 - 18:00"
	3: "Wed: 08:00 - 18:00"
	4: "Thu: 08:00 - 18:00"
	5: "Fri: 08:00 - 18:00"
	6: "Sat: Closed all day"
  },
  opening_notes: "All Year"

  image_cdn: "https://res.cloudinary.com/rdl/image/upload/"
  default_image_path: "restaurants/EN03392596/dbh7yg82buiqmrfbamny.jpg",

  attributes: {
  	0: "Children Welcome"
  	1: "Wheelchair Access"
  	2: "Vegetarian Options"
  	3: "Reservations"
  	4: "Internet Booking"
  },

  description: "This is for a full description of the restaurant and will primarily be used for display on the restaurants landing page, or Single Page Website (SPW). This description can be used to describe the restaurant's style, cuisine, ethos, ambience, decor, location etc. in much greater detail, and to highlight its key features. It can be up to 5000 characters in length.",

  last_updated: "2019-06-13T09:45:14.000Z",
}

Responsive image examples

Images are served by the Cloudinary CDN and can be requested at any size. An https request can be constructed as follows:

Originally uploaded image

<image_cdn> + <image_path>

e.g. https://res.cloudinary.com/rdl/image/upload/restaurants/EN03392596/dbh7yg82buiqmrfbamny.jpg

400 x 300px image (centre cropped/filled)

<image_cdn> + 'c_fill,w_400,h_300' + <image_path>

e.g. https://res.cloudinary.com/rdl/image/upload/c_fill,w_400,h_300/restaurants/EN03392596/dbh7yg82buiqmrfbamny.jpg

Square 120px thumbnail image (centre cropped/filled)

<image_cdn> + 'c_fill,w_120,h_120' + <image_path>

e.g. https://res.cloudinary.com/rdl/image/upload/c_fill,w_120,h_120/restaurants/EN03392596/dbh7yg82buiqmrfbamny.jpg
